Product Details
Place of Origin: Shenzhen, China
Brand Name: SUNTOR
Certification: FCC, CE, RoHS
Model Number: ST6222CZ-HD
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Box
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000 set/ month
Modulation: |
COFDM |
Working Frequency: |
300MHz～4.4GHz |
Output Power: |
20W |
Channel Bandwidth: |
2/2.5/4/8MHz |
Code Stream: |
2Mbps～12Mbps |
Compression Format: |
H.264/MPEG-2 |
Video Input: |
HD-SDI, High Definition Multimedia Interface And Analog CVBS |
Transmission Range: |
NLOS Distance: 10-20km LOS Horizontal Distance: 20-30km Air To Ground: 30~50km |
Modulation: |
COFDM |
Working Frequency: |
300MHz～4.4GHz |
Output Power: |
20W |
Channel Bandwidth: |
2/2.5/4/8MHz |
Code Stream: |
2Mbps～12Mbps |
Compression Format: |
H.264/MPEG-2 |
Video Input: |
HD-SDI, High Definition Multimedia Interface And Analog CVBS |
Transmission Range: |
NLOS Distance: 10-20km LOS Horizontal Distance: 20-30km Air To Ground: 30~50km |
Two way Audio Vehicle Mounted Long Range COFDM Wireless Video Transmitter Receiver
Introduction:
ST6222CZ-HD is a digital wireless video transmitter ,specially dsigned for vehicle-mounted application, could transmit high quality video signal in city or on sea where appears multipath effect always.It can realise wide signal coverage without directional antenna depend on its excellent "Diffract" ability .
It can simultaneously transmit one way image, one way Full-duplex bidirectional audio and data.
Features:
New powerful HD COFDM video audio transmitter, it can up to 10-40W RF power which support transmitting over a long distance.
Using the core technology 4th generation mobile communication COFDM modulation and low delay full-HD 1080P technique that can transmit high quality and stable image under the condition of fast moving or many buildings as obstacles (NLOS)
Suitable for vehicles: cars, boat - boats, cars - a building, ship-a base station, aircraft-a building/vehicle and more. High-definition moving video signal transmission, the carrier velocity greater than 450kph
Widely used in public security, armed , fire, rescue, reconnaissance, field operations and other emergency communication system.
Transmitter parameter
| RF | Working frequency | 300MHz～4.4GHz |
| Output power | 20W | |
| Modulation | COFDM | |
| Channel bandwidth | 2/2.5/4/8MHz | |
| Encryption | AES | |
| Guard Interval | 1/32, 1/16, 1/8, 1/4 | |
| System | Standard | H.264/MPEG-2 |
| Code stream | 2Mbps～12Mbps | |
| System latency | ≤300ms | |
| Error rate | ≤10-6 | |
| Transmission Range |
NLOS Distance: 10-20km LOS Horizontal Distance: 20-30km Air to Ground: 30~50km |
|
| Usage mode | Vehicle-mounted | |
| Audio and Video | Compression format | H.264/MPEG-2 |
| Video input | HD-SDI, High Definition Multimedia Interface and Analog CVBS | |
| Audio input | Left and Right Channel | |
| Image resolution | 1080P(1920*1080)compatible 720P,480P and SD @ Frame rate is 25 fps | |
| Video input physical interface | BNC female port, HD-SDI, High Definition Multimedia Interface standard interface | |
| Aviation Interface |
Hand Microphone(on front panel) RS485(on back panel) |
|
| Audio input physical interface | BNC female port | |
| Others | Power supply | AC110-230V |
| Size | 19" 2U standard crate,485mm×340 mm×90 mm (L×W×H) | |
| Weight | 5kg |
