CD30HPT UAV Wireless Video Transmitter And Receiver 1080P High Definition Multimedia Interface

Place of Origin Shenzhen, China
Brand Name SUNTOR
Certification CE、 SGS、RoHS
Model Number CD30HPT
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details ABS Plastic Box
Delivery Time 7-15 days
Payment Terms T/T, Western Union, Paypal
Supply Ability 1500 set/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Long Distance 30KM From Air To Ground Rate Double 3-6Mbps
RF Transmitting Power 33dBm Bandwidth 4MHz/8MHz
Weight 93G Dimension 76x73x23mm
Mode QPSK
Highlight

drone transmitter and receiver

,

uav video transmitter

Leave a Message
Product Description

CD30HPT Drone Video Transmitter & Receiver Specifi...



30KM Long Range UAV Data Link Fixed Wing Drones COFDM Transmitter and Receiver



CD30HPT UAV Wireless Video Transmitter And Receiver 1080P High Definition Multimedia Interface 0

CD30HPT UAV Wireless Video Transmitter And Receiver 1080P High Definition Multimedia Interface 1



Application



1.Detection sytems

2.Mapping / GIS

3.Inspection

4.Surveying

5.Science and Academic Research

6.Mining





Introduction:

Suntor utvikler teknologi som effektiviserer søkefasen til fiske-
fartøy som driver pelagisk- og bunnfiske. Vi tilbyr rederier et system og en fremgangsmåte for
lokalisering av fisk og marine arter ved hjelp av ubemannede fjernstyrte
droner. Dronene sender live data tilbake til moderskipet og gir skipperen en oversikt over hvor de nærmeste verdiene befinner seg. Dette med hjelp av avanserte deteksjonssystemer som er utviklet med formål å effektivisere lete fasen, redusere kostnader knyttet til drivstoffbruk, og gjøre oprasjonen mer miljøvennlig.


CD30HPT UAV video professional design mini HD wireless COFDM video transmitter, uav drones mobile communication core COFDM point to point transmitting system. It supports 2.4GHz and suitable for very larger distance 30KM



Key features:



  • Frequency: 2.4Ghz
  • Lowest Latency 50-70ms
  • Video Input: High Definition Multimedia Interface and Ethernet
  • Resolution: Full HD 1080P/60
  • 30-35KM Long-distance from air to ground transmission
  • Support Mavlink,TTL, SBUS Data Transmission Telemetry
  • RJ45+TTL RS232 bidirectional serial port

Warranty:




Products are warranted for 1 year from the date of package signed.



Suntor CD30HPT mini transmitter receiver is a set of real-time image transmission system with mini High Definition Multimedia Interface and RJ45 Ethernet interface drone fixed wing. It converts the real-time signal from the mini High Definition Multimedia Interface camera into RF Power and send back to groud High Definition Multimedia Interface output wirelessly. The returned signal will be received by the accessary receiver and displayed on display screen.



Parameter

Model:CD30HPT
Frequency 2.4GHz (2.402-2.478GHz) Adjustable
RF Transmitting Power

CD30HPT: 33dBm


Frequency Bandwidth 4MHz/8MHz Adjustable
Antenna 1TX 1RX Small Antenna
Transmission Rate Double 3-6Mbps
Encryption AES 128
Transmission Mode PTP
Start-up time < 30s
Transmission Range

ST5NPT: Air to ground 30km


System Latency 50-70ms
Two-way function

Integrate multiple radio links into one to transmit and receive.

Support SBUS/Mavlink/TTL communication module

Optional
Transmitting Rate 100Mbps
Power DC 7-18V DC7~18V Optional
Power Consumption

TX:7W RX:6W





Maximum
Working Temperature

Operating temperature: -40 - 85°C

Storage temperature: -55 - 100°C


IInterface

RJ45 input/output Ethernet High Definition Multimedia Interface Video RS232 Serial Ports


Appearance Design CNC technology/ double aluminum alloy shell with waterproof design
Size 76×73x23mm
Net Weight Tx:146g Rx: 146g





Packaging:



1PCS Tx Antenna 19cm
1PCS Rx Antenna 29cm
1PCS Rx Antenna 14dBi

1PCS TPalyer Key
2PCS High Definition Multimedia Interface Cable

2PCS Feed Antenna Cable

3PCS RS 232 Serial Ports Cable

4PCS Power Cable
4PCS Ethernet Cable

4PCS TTL Data Cable
