1.2GHz Compact Wireless Elevator Camera System , Analog Video Transmission Equipment

  • 1.2GHz Compact Wireless Elevator Camera System , Analog Video Transmission Equipment
Place of Origin China
Brand Name SUNTOR
Certification FCC, CE, RoHS
Model Number TY-1000mW
Minimum Order Quantity 1 set
Payment Terms T/T, Western Union, Paypal
Supply Ability 1000 set/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Modulation FM Frequency 1.2GHz
Transmit Power 1000mW (30dBm) Transmission Range 500-800m (LOS)
Number Of Channels 15CH Transmitter Weight 90g
High Light

audio video wireless transmitter

,

video signal transmitter
Leave a Message
Product Description

1.2GHz compact 1000mW 500-800 meters wireless analog video transmission equipment



TY-1000mW wireless video transmission equipment is an excellent all aspects of performance are more varieties, and its large power margin, more suitable for complex physical environment. The use of 0dB ( Original small antenna) in full to the antenna, the open area to ensure the transmission 500-800m or so, if the raising of the high gain directional antenna, increased to 2 km away. And transmitter technology is superb and the special metal is more conducive to heat, more suitable for long hours of work. Signal input with common AV interface ,it can easily work with camera, VCD, DVD and all other conventional AV interfaces compatible.



Featuers:

  • Wireless transmission: no need to set up communications cable

  • Image, audio sync, color black and white compatible

  • Small size, light weight, easy to carry, good installation

  • Responsive, timely, send and receive real-time transmission

  • Using FM mode, anti-interference ability, good image quality

  • Highly integrated, stable and reliable transmission distance up to 800m

  • DC 12V power supply, easy to use.

Parameters

Model

TY-1000mw

Voltage

DC 12V

Current

400mA

Frequency

983-1280MHz

Number of channels

15CH

Transmit Power

1000mW

Video Output

1 Vp-p(FM)

Audio Output

1 Vp-p(FM)

Audio Carrier Ware

5.5M 6.0M

Distance (Open environment)

500-800m

Overall Configuration

Transmitter, receiver, video cable, power supply, antenna

Temperature

-20℃～+50℃

Transmitter Weight

90g

Receiver Weight

120g

Overall Weight

790g

Dimensions (L * W * H)

Transmitter:88*52*20mm Receiver: 116*80*21mm

Box size (L * W * H)

245*160*65mm
