2.4G 3KM CCTV RS485 Audio Analog Video Transmitting System 1 Watt RF Power

Product Details

Place of Origin: Shenzhen, China

Brand Name: SUNTOR

Certification: FCC, CE, RoHS

Model Number: ST2418SZ-1

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiation

Packaging Details: Carton

Payment Terms: T/T, Western Union, Paypal

Supply Ability: 1000 set/ month

Get Best Price
Contact Now
Specifications
Highlight:

analog wireless transmitter

,

wireless analog transmitter and receiver

,

RS485 Analog Video Transmitter

RF Power:
1 Watt
Signal:
Video, Audio And RS485
Range:
2-3km
Transmit Model:
PTP And PTMP
RF Power:
1 Watt
Signal:
Video, Audio And RS485
Range:
2-3km
Transmit Model:
PTP And PTMP
Description
2.4G 3KM CCTV RS485 Audio Analog Video Transmitting System 1 Watt RF Power

2.4G 3KM CCTV RS485 audio Analog Video Transmitting System



Introduction

ST2418SZ-1 is Economy outdoor waterproof and dustproof wireless audio video and PTZ command transceiver. Transmitting the signals by FM. Long transmission distance, stable performance, digital frequency adjust, waterproof and dustproof with the high resolution prefect image for using in field and harsh environment. The working frequency is S band between 2290 to 2510MHz, complete real-time image transmission, reach 2-3KM above transmission distance, ignore block with repeater together.



Frequency

2290MHz, 2310MHz, 2330MHz, 2350MHz, 2370MHz, 2390MHz, 2410MHz, 2430MHz, 2450MHz,  2470MHz, 2490MHz, 2510MHz


Specifications

Product model ST2418SZ-1

Working frequency 2290MHz 2310MHz 2330MHz 2350MHz 2370MHz 2390MHz
  2410MHz 2430MHz 2450MHz 2470MHz 2490MHz 2510MHz

Appearance Such as picture, the transmitter and receiver have the same
  appearance

Transmission power 1W

Working voltage 220V or 12V

Working poser 10W

Video output 1 Vp-p(FM)

Audio output 1 Vp-p(FM)

Audio 5.5M 6.0M

Transmission range 2000-3000M, (in open air, no obstruction)

Configure Transmitter, receiver, built-in antenna (its easy to install)

Working -20℃~+50℃
temperature

Transmitter weight 3 kg

Receiver weight 2.9kg

Size: (L*W*H) 32*32*7CM

Transmission signal Wireless video, audio and RS485 signals




Installation

  • Waterproof and adjustable frequency for avoiding the frequency interference
  • Bandwidth (2.29-2.51GHz) with the widely adjust range.
  • The traditional connector is transparent (BNC, AV), signal input AV.
  • Power: AC 100-240V or DC12V available according customers requested to meet the solar or battery powered devices.



If there is obstruction, we should be try the best to avoid them.

Firstly, extend the video cable to place the TX and RX higher then obstruction. If cannot this way, find a repeater where can see each other point.





Application

Equipment is suitable place: Building Ground, Orefield, mountain region, stride over river, large factories, large building ground, exercise areas, large parking lots, Oil collection point, etc. Please make sure the NLOS environment between TX and RX. The main obstruction included: Building, mountain, tree (Don't ignore the tree as obstruction)
