NLOS Wireless Mobile Mini Video Transmitter 2 * 2 MIMO For EOD Robot

Place of Origin Shenzhen, China
Certification FCC, CE, RoHS
Model Number ST9601MS
Minimum Order Quantity 1 set
Price Negotiation
Packaging Details Plastic Box
Delivery Time 7-15 days
Payment Terms T/T, Western Union, Paypal
Supply Ability 1000 set/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Frequency Range 570-1443MHz Duplex Mode TDD
Function 2*2 MIMO RF Power 1W
Power DC9-28V Battery DC12V 2600mA
Battery Endurance 2hour Woking Temperatu -20℃~+65℃
High Light

wifi mesh network equipment

,

mesh network module

Leave a Message
Product Description

NLOS wireless mobile IP video MESH networking system for EOD robot



ST9601MS Specs.pdf



Description:
TDD-OFDM broadband wireless mobile emergency communication private network is independent of telecom operators.Its confidentiality,security,mobile performance that is better than the telecom operators,also is a fully transparent data encryption transmission emergency security network. Radio channel coding using TDD-OFDM modulation technology,has ability of two-way transmission support at the same exactly frequency and saving spectrum resources. Whatever,can enable real-time network IP transparent transmission and control and meet the two-way audio and video surveillance network.Real-time monitoring from a central switching the monitor points equipments and corresponding base station working /standby state by a monitor central,which can be better for each mobile front-end monitoring.



Advantages:

  • 1. Advancement: TDD-OFDM channel modulation technology, with ultra-wideband, fully transparent transmission.
  • 2. Security: private network, private communication transport protocol, the only synchronization code, AES encryption.
  • 3. Flexibility: transparent transmission of IP data channel, supports multi-user access.
  • 4. Scalability: all-digital network, is compatible with all IP data transmission equipment.



Application:
Used in special government emergency use, such as: uav, robot, , fire, maritime coastal defense, waterways, ports, digital urban management and other departments.



Technical Parameters

Working Frequency 570-1443MHz Bootloader U-boot
  2412-2462MHz(Wifi) Linux 3.18.19
  1559-1577MHz(GPS) Wired Network IP address configurable
Bandwidth 5/10/20MHz   Subnet Mask Configurable
  20MHz(Wifi) Wireless Network Working Frequency Adjustable
RF Power 0.5-1W   Bandwidth Adjustable
  0.2W(Wifi)   RF Power Adjustable
Receive Sensitivity -92dBm   Support Adhoc
  -90dBm(Wifi)   ESSID/BSSID Configurable
Duplex Mode TDD   Supports adaptive rate and fixed rate modes
Modulation BPSK/QPSK/16-QAM/64-QAM
Diversity Mode Transmitting and receiving diversity   Support Distance Optimization
Upstream and downstream bandwidth Two-way bandwidth up to 80Mbps   Support RTS/CTS Setting
  40Mbps(Wifi)   Connection Status Display
